VENTRICULAR TACHYCARDIA WITH SUCCESSFUL ATP

If ventricular tachycardia occurs in an Implantable Cardioverter Defibrillator (ICD) wearer, the ICD can combat this with 2 different forms of therapy, provided these are activated (which can be done using a programming device). First, the ICD attempts to override the tachycardia. The fastest pacemaker gets control of the heart. If this is not successful, the defibrillator function is used. Here you can see the limb leads. Initially there is a relatively slow ventricular tachycardia.

Dr A Röschl's picture

Ventricular Tachycardia. Unsuccessful Antitachycardia Pacing in an ICD Patient

If ventricular tachycardia occurs in an Implantable Cardioverter Defibrillator (ICD) wearer, the ICD can combat this with 2 different forms of therapy, provided these are activated (which can be done using a programming device). First, the ICD attempts to override the tachycardia. The fastest pacemaker gets control of the heart. If this is not successful, the defibrillator function is used. Here you can see the limb leads. Initially there is a relatively slow ventricular tachycardia with a heart rate of approx. 125 bpm.

Dawn's picture

Anti-tachycardia Function of ICD

This ECG was donated to the ECG Guru by Brent Dubois, and was originally published on the FaceBook page, Paramedic Tips & Tricks.  We published it to this site three years ago, but believe it should be shown again, as it is somewhat rare to catch a good-quality 12-Lead ECG of an implanted cardioverter-defibrillator pacemaer using overdrive pacing to terminate a ventricular tachycardia.  Most of our examples have been rhythm strips.

In this strip, we see the patient in ventricular tachycardia (V tach) at a rate of about 190 / minute.  The ICD, in response to the fast rate, delivers a short burst of even faster paced beats.  The physological rule in the heart is, "the fastest pacemaker controls the heart".  Once the pacemaker has terminated the V tach, it paces at a much slower rate.  It is pacing the atria, and the conduction system is intact, allowing the impulse to travel normally through the ventricles.  If the sinus node is able to "outpace" the slower paced rhythm, the heart will resume a sinus rhythm.

This is called "overdrive pacing" and is done automatically by an ICD that is programmed to do so.  Overdrive pacing can also be accomplished by a temporary transvenous pacer or transcutaneous pacemaker.
